Grant Euroflame Outdoor
The Grant Euroflame economical outdoor oil boiler range has been introduced as a direct response to customer demand for a competitively priced free standing economical condensing boiler designed for situations where internal space is at a premium.
a HeatingFeatures & benefits
The Euroflame models incorporate a new version of the Grant Vortex stainless steel heat exchanger and are extremely efficient having achieved an ‘A’ rating on the SEDBUK and HARP databases.
- High efficiency SEAI HARP ‘A’ Rating
- Features a Riello RDB Burner
- Multiple flueing options
- Optional pipe entry points
- Comes complete with a factory fitted multi-directional flue
- Optional side or rear flue exits
- Fully approved to OFTEC Standard and EC directives
- *One year manufacturer's warranty with five year guarantee on boiler heat exchanger (T&Cs Apply)
Grant announces streamlining of oil boiler ranges
In August 2022, the Grant Vortex and Euroflame oil fired boiler ranges will be streamlined, with many existing models rationalised to simplify the selection and ordering products and making the process more straightforward overall.
Read more here.
Specification
Product code |
Model |
Energy Label |
Product Fiche |
Set Output |
Max Output |
Weight |
Height |
Width |
Depth |
Efficiency |
NOx Emissions |
Tappings Flow/Return |
Burner |
Energy Rating |
Load Profile |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| EFCON5090MOD | Grant Euroflame Outdoor 15-26 | 23.5kW | View | - | 26kW | 113kg | 908mm | 800mm | 505mm | 92.4 | Compliant | 22mm | Riello RDB2.2 | a Heating | - |
| EFCON90120MOD | Grant Euroflame Outdoor 26-36 | 31kW | View | - | 36kW | 142kg | 908mm | 800mm | 505mm | 92.1 | Compliant | 22mm | Riello RDB2.2 | a Heating | - |
Downloads
Accessories
Grant Vortex Mag One Magnetic Filter
- 6 bar max working pressure
- Supplied with spare sealing washers & o-rings
- 360° installation & 1" G.B connections
Fire Valve
- Essential fire protection for oil boilers
- Two alternative temperature settings
- Remote sensing up to 20 meters
Related products
EZ Fit Blue Single Wall Flue Kit
- Stainless steel
- Available as a 1m kit or a 2m telescopic kit
- Extensions available to bring kit to a max of 8m vertically
EZ Fit External Flue (green system) for outdoor boilers
- Suitable for Grant external boilers
- Starter connections available
- Possible to create offsets in straight flue runs by using our 45° bends and extensions.
